- BACH-Chemical Filter Box
- Submit Order
◆Chemical filter box is an environment protection product which is used to remove the waste gas and absorb smells.
◆High adsorption efficiency, obvious effect, wide application, easy to maintain.
◆It can deal with a variety of mixed gases, with the function of removing formaldehyde, benzene, TVOC and other harmful gases, plays a role of disinfection and deodorization.
◆The exhaust gas is treated by the activated carbon filter box through fan power with positive or negative pressure.
| Model | Air Flow | air velocity | filtration | Box Dimension | Tuyere Size(mm) | lengthen box size | |
| W×H×L | |||||||
| (m3/h) | m/s | （mm） | rectangular | circular | （mm） | ||
| BACH-3000 | 3000 | 7 | 3 | 825×993×2600 | 400×320 | Φ400 | 450 |
| BACH-3000F | 825×993×3150 | ||||||
| BACH-6000 | 6000 | 7 | 3 | 825×1513×2600 | 500×500 | Φ560 | 700 |
| BACH-6000F | 825×1513×3350 | ||||||
| BACH-9000 | 9000 | 7 | 3 | 1140×1513×2600 | 630×630 | Φ700 | 700 |
| BACH-9000F | 1140×1513×3350 | ||||||
| BACH-12000 | 12000 | 7 | 3 | 1360×1513×2600 | 800×630 | Φ800 | 700 |
| BACH-12000F | 1360×1513×3500 | ||||||
| BACH-15000 | 15000 | 7 | 3 | 1675×1513×2600 | 1000×630 | Φ900 | 800 |
| 800×800 | |||||||
| BACH-15000F | 1675×1513×3500 | 1250×500 | |||||
| BACH-18000 | 18000 | 7 | 3 | 1360×2138×2600 | 1000×800 | Φ1000 | 1000 |
| BACH-18000F | 1360×2138×3800 | ||||||
| BACH-22500 | 22500 | 7 | 3 | 1675×2138×2600 | 1000×1000 | Φ1120 | 1000 |
| BACH-22500F | 1675×2138×4000 | ||||||
| BACH-27000 | 27000 | 7 | 3 | 1985×2138×2600 | 1250×1000 | Φ1250 | 1100 |
| BACH-27000F | 1985×2138×4200 | ||||||
Remark:The BACH filter box container Fan when its model have letter F;
HEFIL makes various of other models’ BACH filter not listed in above table. Please consult with us if you need.
◆Activated chemical box is an environment protection product which is used to remove the waste gas and absorb smells.
◆High adsorption efficiency, obvious effect, wide application, easy to maintain.
◆It can deal with a variety of mixed gases, with the function of removing formaldehyde, benzene, TVOC and other harmful gases, plays a role of disinfection and deodorization.
◆The exhaust gas is treated by the activated carbon filter box through fan power with positive or negative pressure.
Filters Mainly Configurable
◆As per customers’ different requests, filter box is generally equipped with filters as below (please refer to products description for detailed information).
◆HACH: V-bank Activated Carbon Filter
◆HACF: Activated Carbon Flat Filter
◆HACB: Activated Carbon Filter Box
◆HACT: Activated Carbon Filter Cylinder
◆HACP: Activated Carbon Panel Filter
◆HACD: Activated Carbon Pocket Filter
◆HACM: Potassium Permanganate Chemical Filter
◆HACV: Mini-Pleat Chemical Resin Filter
◆It is widely applied to the treatment of waste gases which is produced during the producing of electronic components, battery (storage-battery), acid pickling, laboratory ventilation, metallurgy, chemical industry, pharmaceutical, coating, food, and brewing.
Application case:
1.Oxide treatment system:
2.Movable chemical filtration box:
3.Activated carbon box:
4.Exhausted gas filtration box:
