HDU-Disposable HEPA Box
◆Trapping 99.99% or higher of 0.3μm particles
◆High-quality galvanized steel sheet, aluminum alloy extrusions or stainless steel frame with externally applied fireproof heat-insulator
◆Adopt computer-controlled automatic production line for manufacture of mini pleat filter material, occupies small space
◆Using special glass fiber filter paper as the filter material, low resistance and large air volume

Submit Order
SpecificationFeatures Frame structureApplication
Model Box Dimensions
(mm)
Inlet Diameter
(mm)
Initial Pressure Drop (Pa) @ Air Flow (m3/h)
HDU-570 570×570×150 Φ250 Φ300 Φ350 100@500 125@620 150@780 180@870
HDU-600 600×600×150 100@550 125@690 150@870 180@970
HDU-610 610×610×150 100@570 125@715 150@900 180@1000
HDU-1170 1170×570×150 100@1030 125@1290 150@1630 180@1800
HDU-1200 1200×600×150 100@1100 125@1390 150@1760 180@1950
HDU-1210 1210×600×150 100@1120 125@1400 150@1780 180@1970
HDU-1220 1220×610×150 100@1150 125@1440 150@1820 180@2020
HEFIL makes various other models of HDU box not listed the above table. Please consult with us if you need.
◆Compact structure, low-cost investment, easy installation and maintenance
◆Air outlet with a high-quality aluminum or stainless expanded sheet has a generous appearance
◆Each HEPA box is through rigorous testing

◆Air outlet with a high-quality aluminum or stainless expanded sheet has a generous appearance

HDU-Disposable HEPA Box



◆Suitable as terminal filtration of air supply system in clean workshops and clean rooms required the high cleanliness. Availably to ensure air flow speed and prevent swirl.
